20FT Portable Prefabricated Modular Shipping Living Flat Pack Container House
Flat pack container house: Flexibility combination, the construction enables compounding of individual container house in transverse or longitudinal directions without limits, and can also be stacked 2~4 stories, to enlarge the space and function. The top, bottom and around the container house used heat insulation, heat preservation materials, providing comfortable temperature for the internal living.
Detailed Specification
| Welding container | 1.5mm corrugated steel sheet, 2.0mm steel sheet, column, steel keel, insulation, floor decking |
| Type | 20ft: W2438*L6058*H2591mm (2896mm is also available)40ft: W2438*L12192*H2896mm |
| Ceiling and Wall inside decoration board | 1) 9mm bamboo-wood fiberboard2) gypsum board |
| Door | 1) steel single or double door2) PVC/Aluminum glass sliding door |
| Window | 1) PVC sliding (up and down) window2) Glass curtain wall |
| Floor | 1) 12mm thickness ceramic tiles (600*600mm, 300*300mm)2) solid wood floor3) laminated wood floor |
| Electric units | CE, UL, SAA certificate are available |
| Sanitary units | CE, UL, Watermark certificate are available |
| Furniture | Sofa, bed, kitchen cabinet, wardrobe, table, chair are available |
Affordable Flat Pack Container Houses is a kind of container house consists by container roof, container base, four columns and wall panels. We have prefabricated all above parts in our factory, so the container roof will be integrated one piece with PU foam for insulation, with electrical system embedded and ready for connecting. The door and windows are installed into the wall panel, conduits, cable, sockets and switches are also well pre-installed.
Flat pack container house features
1. can be relocated anywhere needed, with a crane or forklift.and if necessary, it can be knocked down to save transportation fee.
2. can be flexibly designed, such as you want to add/delete a partition wall, or making a bedroom temporarily.
3. can be conveniently transported with a truck, without moving any items in the house.
4. can be easily built up/knocked down with simple tools such as spanner,hand drillers, etc.
5. elegant,clear enough, removable, can be combined, etc....so, it can be used for site office, staff camp, temporary school, hospital, emergency relief sheds, etc.
6. earthquake resistant 9th, and 210 km/h wind resistant.
